| Dimensions: |
Wheelbase |
2950 mm |
|
Track (front) |
1650 mm |
|
Track
(back) |
1600 mm |
| |
Length |
4395 mm |
| |
Width |
2000 mm |
|
Height |
1000 mm |
|
Weight |
505 kg |
| Engine |
Mugen/Honda ZA5C |
| Clutch |
AP 5.5
inch triple-plate carbon fibre, hydraulically operated |
| Number
of valves |
40 |
| Gearbox |
Lotus,
6-speed semi-automatic transversal transmission |
| Brakes |
AP calipers, AP/Hitco and
Carbone Industrie discs and pads |
| Wheels |
OZ,
11x13 (front), 13.7x13 (rear) |
| Tyres |
Goodyear Eagle |
| Suspension |
Fabricated
steel uprights and wishbones plus inboard spring damper operated by
carbon fibre pushrods. Option for front and rear anti-roll bars. |
| Monocoque |
Carbon fibre skinned
aluminum honeycomb sandwich. One piece moulding with integral internal
structure. |
| Fuel
tank |
Lotus,
central single rubberized fabric cell |
| Bodywork |
Carbon fibre one piece
engine cover, with separate sidepods, one piece underbody/rear
diffuser. Nosebox to meet FISA requirements with energy absorbing
carbon composite structure |
| Winds |
Carbon
fibre with adjustable flaps, front and rear |
|
Colling
system |
Swept back left-hand and
right hand radiators with oil/water heat exchanger on left hand side |
|
Lubrication |
Dry sump
engine oil tank incorporated within the gearbox casing |
|
Electrics |
Cranfield gearbox
controller and data acquisition system with chassis wiring by Raychem
to Team Lotus design |
|
|
|
